| Frame |
Alpha Platinum Aluminium, internal storage, tapered head tube, Knock Block 2.0, Control Freak internal routing, down tube guard, shuttle guard, threaded BB, ISCG 05, 34.9 mm seat tube, magnesium rocker link, Mino Link, ABP, Boost148, 160 mm travel |
| Fork |
RockShox ZEB Select, DebonAir spring, Charger RC damper, tapered steerer, 44mm offset, Boost110, Maxle Stealth, 170mm travel |
| Shock |
RockShox Super Deluxe Select+ RT, 230mm x 62.5mm |
| Max compatible fork travel |
180mm (596mm axle-to-crown) |
| |
|
| |
|
| Wheel front |
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle |
| Wheel rear |
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Rapid Drive 54, SRAM XD driver, Boost148, 12 mm thru axle |
| Skewer rear |
Bontrager Switch thru axle, removable lever |
| Tire |
Bontrager XR5 Team Issue, Tubeless Ready, aramid bead, 120 tpi, 29x2.50" |
| Tire part |
Bontrager TLR sealant, 180 ml/6 oz |
| Rim strip |
Bontrager TLR |
| Max tire size |
Frame: 29x2.50" Fork: See manufacturer |
| |
|
| |
|
| Shifter |
SRAM GX Eagle, 12 speed |
| Rear derailleur |
SRAM GX Eagle |
| Crank |
SRAM X1 Eagle, DUB, 30T steel ring, Boost (55 mm chain line), 170 mm length |
| Bottom bracket |
SRAM DUB MTB Wide, 73mm, BSA threaded |
| Cassette |
SRAM Eagle XG-1275, 10-52, 12 speed |
| Chain |
SRAM GX Eagle, 12 speed |
| Max chainring size |
Max: 34T, Min 28T |
| |
|
| |
|
| Saddle |
Bontrager Arvada, hollow chromoly rails, 138 mm width |
|
*Seatpost
|
Size: S
TranzX JD-YSP39, 100 mm travel, internal routing, 34.9 mm |
Size: M , ML
TranzX JD-YSP39, 150 mm travel, internal routing, 34.9 mm |
Size: L , XL
TranzX JD-YSP39, 170 mm travel, internal routing, 34.9 mm |
| Handlebar |
Bontrager Line, alloy, 35 mm, 27.5 mm rise, 820 mm width |
| Grips |
Bontrager XR Trail Pro, alloy lock-on |
| Stem |
Bontrager Elite, 35 mm, 0-degree, 35 mm length |
| Headset |
Knock Block 2.0 Integrated, 72-degree radius (includes infinite-radius chip), sealed cartridge bearing, 1-1/8" top, 1.5" bottom |
| Brake |
SRAM Code R 4-piston hydraulic disc |
|
*Brake rotor
|
Size: S , M , ML , L , XL
SRAM CenterLine, 6-bolt, round edge, 180 mm |
Size: S , M , ML , L , XL
SRAM CenterLine, 6-bolt, round edge, 200 mm |
| Rotor size |
Max brake rotor sizes: Front see fork manufacturer, rear 200mm |
| |
|
| |
|
| Bag |
Bontrager BITS Internal Frame Storage Bag |
| |
|
| |
|
| Weight |
M - 15.50 kg / 34.18 lbs |
| Weight limit |
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
