Frame
Premium Alpha Platinum Aluminum frame, top-load PowerPack, integrated cockpit routing, 135x5mm QR
Fork
Verve+ alloy, threadless steel steerer, ThruSkew QR
Wheels
Hub front
Formula DC-20, alloy, 6-bolt, 100x5mm
Skewer front
132x5mm QR, ThruSkew
Hub rear
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm
Skewer rear
155x5mm QR
Rim
Bontrager Connection, double-wall, 32-hole, 20mm width, schrader valve
Spokes
14g stainless steel, black
Tire
Bontrager E6 Hard-Case Lite, reflective, wire bead, 60tpi, 27.5x2.4"
Max tire size
27.5x2.40" with or without fenders
E-system
Battery
Bosch PowerPack 545Wh, smart system
Charger
Bosch standard 2A, 110V, smart system
Computer
Bosch Purion 200
Motor
Bosch Performance Line, 250W, 75Nm, 32km/h
E-bike Classification
Class 1
Drivetrain
Shifter
Shimano U4000, 9 speed
Rear derailleur
Shimano CUES U4000
Crank
ProWheel alloy, 170mm length
Chain ring
ProWheel 38T narrow/wide steel, w/alloy guard
Cassette
Shimano LINKGLIDE LG300, 11-46, 9 speed
Chain
Shimano LG500, 9/10/11 speed
Pedal
Bontrager City pedals
Max chainring size
1x: 46T
Components
Saddle
Bontrager Boulevard
Seatpost
Alloy, suspension, 31.6 mm, 300 mm length
*Handlebar
Size: M
Bontrager alloy, 31.8mm, comfort sweep, 620mm width
Size: L, XL
Bontrager alloy, 31.8mm, comfort sweep, 660mm width
Grips
Trek Line Ergonomic Pro, lock-on
*Stem
Size: M
Bontrager alloy, 31.8 mm clamp, adjustable rise, Blendr-compatible, 85 mm length
Size: L, XL
Bontrager alloy, 31.8 mm clamp, adjustable rise, Blendr-compatible, 105 mm length
Brake
Shimano MT200 hydraulic disc
Brake rotor
Shimano RT26, 6-bolt, 180mm
Rotor size
Max brake rotor sizes: 180mm front & rear
Accessories
*Light
Size: M, L, XL
Herrmans H-Black MR4-E, 120 Lumen, 40 Lux, LED, headlight
Size: M, L, XL
Spanninga SOLO for e-bike, taillight
Kickstand
Adjustable length rear mount alloy kickstand
Cargo rack
Alloy rear rack, 25kg max weight
*Fender
Size: M, L, XL
SKS plastic, rear
Size: M, L, XL
SKS wide, plastic
Weight
Weight
M - 27.29 kg / 60.17 lbs
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, materials, and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based off pre-production painted frames at time of publication. Weights may vary in final production.
