*Frame

Size: XS

Alpha Gold Aluminum, curved top tube, tapered head tube, internal routing, rack, fender, and kickstand mount, UDH, Boost148, 12mm thru axle

Size: S , M , L , XL

Alpha Gold Aluminum, tapered head tube, internal routing, rack, fender, and kickstand mount, UDH, Boost148, 12mm thru axle

*Fork

Size: XS

SR Suntour XCM 34, air spring, lockout, tapered steerer, 44mm offset, Boost110, 15mm thru axle, 100mm travel

Size: S , M , L , XL

SR Suntour XCM 34, air spring, lockout, tapered steerer, 44mm offset, Boost110, 15mm thru axle, 120mm travel

Wheels

Hub front

Shimano TC500 alloy, centerlock, 110x15mm thru axle

Hub rear

Shimano TC500 alloy, centerlock, 148x12mm thru axle

Skewer rear

Bontrager Switch thru axle, removable lever

Rim

Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve

*Tire

Size: XS , S

Bontrager Montrose comp, wire bead, 30 tpi, 27.5x2.40"

Size: XS , S

Bontrager Montrose Comp, wire bead, 30 tpi, 27.5x2.4''

Size: M , L , XL

Bontrager Montrose Comp, wire bead, 30 tpi, 29x2.4''

Size: M , L , XL

Bontrager Montrose comp, wire bead, 30 tpi, 29x2.40"

Max tire size

Frame: 29x2.60" (XS: 27.6x2.60"), Fork: See manufacturer

E-system

Battery

Bosch CompactTube 400Wh

Charger

Bosch standard 2A, 110V, smart system

Computer

Bosch Purion 200

Motor

Bosch Active Line Plus, 50 Nm

E-bike Classification

Class 1

Drivetrain

Shifter

Shimano U4000, 9 speed

Rear derailleur

Shimano CUES U4000

Crank

FSA CK-220, 165mm length

Chain ring

FSA, 32T, steel

Cassette

Shimano LINKGLIDE LG300, 11-46, 9 speed

Chain

Shimano LG500

Pedal

VP-536 nylon platform

Max chainring size

1x: 36T, min 32T

Components

Saddle

Bontrager Verse P3, steel rails

*Seatpost

Size: XS , S

TranzX JD-YSI34, 100mm travel, internal routing, 31.6mm, 350mm length

Size: M , L

TranzX JD-YSI34, 150mm travel, internal routing, 31.6mm, 456mm length

Size: XL

TranzX JD-YSI34, 170mm travel, internal routing, 31.6mm, 500mm length

*Handlebar

Size: XS , S

Bontrager alloy, 31.8mm, 15mm rise, 720mm width

Size: M , L , XL
Bontrager Comp, alloy, 31.8mm, 40mm rise, 780mm width

Grips

Trek Line Comp, nylon lock-on

*Stem

Size: XS , S

Bontrager Comp, 31.8mm, 7 degree, 35mm length

Size: M , L
Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length

Size: XL
Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 60mm length

Headset

Semi-integrated, loose ball bearing, 1-1/8" top, 1.5" bottom

Brake rotor

Tektro, centerlock, 203mm

Brake Set

Tektro HD-M275 hydraulic disc

Rotor size

Max brake rotor sizes - Frame: 203mm, min 180mm, Fork: see fork manufacturer

Weight

Weight

M - 22.90 kg / 50.49 lbs (with tubes)

Weight limit

This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).

We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, materials, and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.

Bike and frame weights are based off pre-production painted frames at time of publication. Weights may vary in final production.
