*Frame

Size: XXS , XS

Alpha Silver Aluminum, curved top tube, internal derailleur & dropper post routing, rack and kickstand mount, 135x5mm ThruSkew

Size: ML , M , L , S , XL

Alpha Silver Aluminum, internal derailleur & dropper post routing, rack and kickstand mount, 135x5mm ThruSkew

*Fork

Size: XXS

SR Suntour XCM 30, coil spring, preload, hydraulic lockout, 42mm offset for 26" wheel, 100mm QR, 100mm travel

Size: XS

SR Suntour XCE 28, coil spring, preload, 42mm offset for 27.5'' wheel, 100mm QR, 80mm travel

Size: S

SR Suntour XCE 28, coil spring, preload, 42mm offset for 27.5'' wheel, 100mm QR, 100mm travel

Size: ML , M , L , XL

SR Suntour XCE 28, coil spring, preload, 46mm offset for 29'' wheel, 100mm QR, 100mm travel

Wheels

Hub front

Formula DC-20, alloy, 6-bolt, 5x100 mm QR

Hub rear

Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR

Skewer rear

173x5mm QR

Rim

Bontrager Connection, double-wall, 32-hole, 20mm width, schrader valve

*Tire

Size: XXS

Bontrager Montrose Comp, wire bead, 30 tpi, 26x2.35''

Size: XS , S

Bontrager Montrose comp, wire bead, 30 tpi, 27.5x2.40"

Size: ML , M , L , XL

Bontrager Montrose comp, wire bead, 30 tpi, 29x2.40"

Drivetrain

Shifter

Shimano M315, 8 speed

Rear derailleur

Shimano ESSA U2000

*Crank

Size: XXS , XS

ProWheel alloy, 32T narrow-wide steel ring, 160mm length

Size: ML , M , S

ProWheel alloy, 32T narrow-wide steel ring, 170mm length

Size: L , XL

ProWheel alloy, 32T narrow-wide steel ring, 175mm length

Cassette

Shimano HG300, 11-45, 8 speed

Chain

KMC Z8.3, 8 speed

Pedal

nylon platform

Components

Saddle

Bontrager Verse Short, stainless steel rails

*Seatpost

Size: XXS

Bontrager alloy, 31.6 mm, 12 mm offset, 300 mm length

Size: M , XS , S

Bontrager alloy, 31.6mm, 12mm offset, 330mm length

Size: ML , L , XL

Bontrager alloy, 31.6mm, 12mm offset, 400mm length

*Handlebar

Size: XXS , XS

Bontrager alloy, 31.8mm, 5mm rise, 690mm width

Size: S

Bontrager alloy, 31.8mm, 15mm rise, 720mm width

Size: ML , M , L , XL

Bontrager alloy, 31.8mm, 15mm rise, 750mm width

Grips

Trek Line Comp, nylon lock-on

*Stem

Size: XXS , XS , S

Bontrager Comp, 31.8mm, 7 degree, 35mm length

Size: ML , M , L
Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length

Size: XL
Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 60mm length

Headset

Semi-integrated, 1-1/8''

*Brake

Size: XXS , XS , S

Tektro HD-M276 hydraulic disc

Size: ML , M , XXS , XS , L , S , XL

Power BH-M286TF hydraulic disc, 160mm rotor

Size: ML , M , L , XL

Tektro HD-M275 hydraulic disc

Size: ML , M , L , XL

Power BH-M286TF hydraulic disc, 180mm rotor

*Brake rotor

Size: ML , M , XXS , XS , L , S , XL

Tektro, 6-bolt, 160mm

Size: ML , M , L , XL

Tektro, 6-bolt, 180mm

Weight

Weight

M - 14.90 kg / 32.85 lbs

Weight limit

This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).

We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, materials, and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.

Bike and frame weights are based off pre-production painted frames at time of publication. Weights may vary in final production.
