Frame with Fork

900 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic-only routing, removable aero chainkeeper, T47 BB, flat mount disc, UDH, 142x12mm thru axle

Fork

Madone Gen 8 one-piece carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm chamfered thru axle

Weight

Weight

ML - 7.22 kg / 15.92 lbs (with TLR sealant, no tubes, no bottles/cages)

Weight limit

This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg).

E-system

Battery

SRAM AXS battery pack (with charger)

Drivetrain

Shifter

SRAM Force AXS E1

Front derailleur

SRAM Force AXS, braze-on

Rear derailleur

SRAM Force AXS, 36T max cog

*Crank

Size: XS, S

SRAM Force AXS with power meter, 48/35, DUB, 160mm length

Size: XS, S, M, ML

SRAM Force AXS with power meter, 48/35, DUB, 165mm length

Size: M, ML, L, XL

SRAM Force AXS with power meter, 48/35, DUB, 170mm length

Size: L, XL

SRAM Force AXS with power meter, 48/35, DUB, 172.5mm length

Bottom bracket

SRAM DUB, T47 threaded, internal bearing

Cassette

SRAM Force XG-1270, 10-33, 12 speed

Chain

SRAM Force E1, 12/13 speed

Max chainring size

1x: 54T, 2x: 56/43

Wheels

Wheel front

Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, 100x12mm thru axle

Wheel rear

Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, SRAM XD-R driver, 142x12mm thru axle

Skewer front

Bontrager Switch chamfered thru axle

Skewer rear

Bontrager Switch chamfered thru axle, removable lever

*Tire

Size: XS, S, M, ML, L, XL
Bontrager Aeolus RSL RD, Tubeless Ready, cotton construction, aramid bead, 170 tpi, 700x28mm

Size: XS, S, M, ML, L, XL

Pirelli P Zero Race TLR RS, 120 tpi, tubeless compatible, 700x28mm

Tube

Pirelli P Zero SmarTube, TPU

Max tire size

32mm (as measured, see manual for details)

Components

*Saddle

Size: XS, S, M, ML, L, XL
Bontrager Aeolus Pro, carbon rails, 145mm width

Size: XS, S, M, ML, L, XL
Trek Aeolus Pro, carbon fiber rails, AirLoom lattice 145mm width

Seatpost

Madone aero carbon seatpost, 0mm offset, short length

*Handlebar/stem (integrated)

Size: XS
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80mm reach, 124mm drop, 35cm control width, 38cm drop width, 80mm stem length

Size: S
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80mm reach, 124mm drop, 37cm control width, 40cm drop width, 90mm stem length

Size: M
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80mm reach, 124mm drop, 39cm control width, 42cm drop width, 90mm stem length

Size: ML, L
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80mm reach, 124mm drop, 39cm control width, 42cm drop width, 100mm stem length

Size: XL
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80mm reach, 124mm drop, 41cm control width, 44cm drop width, 110mm stem length

Handlebar tape

Trek EcoTack

Brake

SRAM Force AXS hydraulic disc, flat mount

*Brake rotor

Size: XS, S, M, ML, L, XL

SRAM CenterLine X, centerlock, round edge, 160mm

Size: XS, S, M, ML, L, XL

SRAM Paceline X, rounded, centerlock, 160mm

Rotor size

Max brake rotor sizes: 180mm front, 160mm rear

We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, materials, and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.

Bike and frame weights are based off pre-production painted frames at time of publication. Weights may vary in final production.
