Frame

300 Series Alpha Aluminum, TQ drive system, hidden fender mounts, rack mounts, integrated frame bag mounts, internal cable routing, flat mount disc, integrated chainkeeper, UDH, 142x12mm chamfered thru axle

Fork

Domane+ carbon, tapered carbon steerer, fender mounts, flat mount disc, 12x100mm thru axle

Weight

Weight

ML - 14.39 kg / 31.73 lbs (with TLR sealant, no tubes)

Weight limit

This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg).

E-system

Battery

TQ 360Wh

Charger

TQ 4A charger

Controller

TQ color LED display with Bluetooth & ANT+ connectivity

Computer

TQ LED display with Bluetooth & ANT+ connectivity

Motor

TQ-HPR60, 60 Nm, 300 watt maximum continuous rated power, 350 watt peak power

Drivetrain

Shifter

SRAM Apex, 12 speed

Rear derailleur

SRAM Apex XPLR, 44T max cog

*Crank

Size: S, XS

Praxis Alloy, 165mm length

Size: M, ML

Praxis Alloy, 170mm length

Size: XL, L

Praxis Alloy, 172.5mm length

Cassette

SRAM XPLR PG-1231, 11-44, 12 speed

Chain

SRAM Apex, 12 speed

Max chainring size

1x: 46T

Wheels

Hub front

Bontrager alloy, sealed bearing, centerlock disc, 100x12mm thru axle

Skewer front

Bontrager Switch chamfered thru axle

Skewer rear

Bontrager Switch chamfered thru axle, removable lever

Rim

Bontrager Paradigm 23, Tubeless Ready, 24-hole, 23mm width, Presta valve

Spokes

14g stainless steel, black

Tire

Bontrager Kwaremont Pro GR, tubeless ready, folding bead, dual compound, 120 tpi, 700x32mm

Tire part

Bontrager TLR sealant, 180 ml/6 oz

Max tire size

40mm without fenders, 35mm with fenders

Components

Saddle

Verse Short Comp, steel rails, 145mm width

Seatpost

Bontrager alloy, 27.2mm, 12mm offset, 330mm length

*Handlebar

Size: XS
Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 36cm control width, 40cm drop width

Size: S
Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 38cm control width, 42cm drop width

Size: M, ML
Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 40cm control width, 44cm drop width

Size: XL, L
Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 42cm control width, 46cm drop width

Handlebar tape

Trek EcoTack

*Stem

Size: XS
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 70mm length

Size: S
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length

Size: M
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 90mm length

Size: L, ML
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 100mm length

Size: XL

Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 110mm length

Brake

SRAM Apex D1 hydraulic disc, flat mount

Brake rotor

SRAM Paceline, rounded, centerlock, 160mm

Brake lever

SRAM Apex, 12 speed

Rotor size

Max brake rotor sizes: 160mm front & rear

We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, materials, and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.

Bike and frame weights are based off pre-production painted frames at time of publication. Weights may vary in final production.
